Magnetic sensor MSK320R
Incremental, redundant signal outputs, scaling factor selectable
- Enhanced safety owing to independent output channels
- 2 magnetic sensors and 2 signal conditioners in one sensor head
- Works with MB320/1 magnetic tape, MRI01 or MR320 magnetic ring, MBR320 magnetic tape ring
- Reading distance ≤2 mm
- Repeat accuracy ±1 increment
- extensive application temperature range of -40 … 85° C
- Cost advantage by installation of one MSK320R sensor instead of two MSK320 sensors
Technical drawing
Technical data
Signal image
Note
The logic state of signals A1/B1 relating to signals A2/B2 is not defined. The phasing A1/B1 and A2/B2 may deviate from the signal pattern.
More information
pin assignment
inverted
|
Signal |
Cable color |
|
+UB |
brown |
|
GND |
black |
|
A1 |
red |
|
B1 |
orange |
|
/A1 |
yellow |
|
/B1 |
green |
|
A2 |
blue |
|
B2 |
violet |
|
/A2 |
white |
|
/B2 |
gray |
Hint for mounting
|
A, Sensor/ring reading distance |
≤2 mm |
|
B, Lateral offset |
±2 mm |
|
C, Alignment error |
±3° |
|
D, Longitudinal inclination |
±1° |
|
E, Lateral inclination |
±3° |
Order
Product configuration
Feature
Select specifications
Additional information
Cable length
01.0
resolution linear/
scaling factor radial a1/
b1
0.0125/64
resolution linear/
scaling factor radial a2/
b2
0.0125/64
Comparable products
Scope of delivery
- MSK320R
- Installation Instructions
