Translation module AS510/1
incremental, interface, resolution 5 μm
- Parameters adjustable via DIP switches
- Resolution up to 5 μm
- Reference signal with intervals of 5 mm
- Works with sensor MS500
Ben
King
Inside Sales
Edward
Stuart
Product Manager Business Unit MagLine
Technical drawing
Technical data
Mechanical data
Electrical data
System data
Ambient conditions
Feature
Technical data
Additional information
Housing
steel sheet
electrogalvanized
Feature
Technical data
Additional information
Operating voltage
24 V DC ±20 %
reverse polarity protection
5 V DC ±5 %
no reverse polarity protection
Current consumption
70 mA
Output circuit
PP, LD (RS422)
switchover via DIP switches
Output signals
A, /A, B, /B, 0, /0
Real-time requirement
speed-proportional signal output
Type of connection
D-Sub
9-pole (supply and signal output)
mini-DIN
6-pole socket (sensor)
Feature
Technical data
Additional information
Resolution
5, 10, 20, 25, 50, 100 µm
with quadruple evalution selectable via DIP switch
System accuracy
at TU = 20° C ±(0.025 + 0.01 x L) mm, L in m
with MB500 and 0.05 mm accuracy class
Repeat accuracy
±1 Increment(s)
Travel speed
≤20 m/s
sensor
Feature
Technical data
Additional information
Ambient temperature
0 … 70 °C
Storage temperature
-20 … 70 °C
Relative humidity
≤95 %
condensation inadmissible
EMC
EN 61000-6-2
interference resistance / immission
EN 61000-6-4
emitted interference / emission
Protection category
IP40
EN 60529
More information
pin assignment
|
Signal |
PIN |
|
A |
1 |
|
A/ |
2 |
|
"GND (for output signal) " |
3 |
|
B |
4 |
|
B/ |
5 |
|
0 |
6 |
|
0/ |
7 |
|
+UB |
8 |
|
GND (for supply) |
9 |
Order
Product configuration
Feature
Select specifications
Additional information
Select your specifications:
Operating voltage
4
reverse polarity protection
no reverse polarity protection
Scope of delivery
- AS510/1
- User information
